Name: API Standard TCI Tricone Rock Bit 200mm IADC545 Mining / Water Well Drill
Brand: Glorytek Industry (Beijing) Co., Ltd.
SKU: 200mm IADC545
Price: 10,350.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Name: API Standard TCI 200mm IADC545 Tricone Rock Bit / Mining / Water Well / Drill Bit

Keyword: 200mm IADC545 Tricone Rock Bit

IADC Code: IADC545 525, Etc.

Size: 200mm 7 7/8"

Colors: Black, Blue, Red, Yellow, Silver Etc.

Application: Rock Drilling, Well Drilling, HDD

Highlight:

API Standard tricone rock bit

200 mm tricone rock bit

tricone bit IADC545

Basic Infomation

Place of Origin: China

Brand Name: GLORYTEK

Certification: SGS, TUV

Model Number: 200mm IADC545

Payment & Shipping Terms

Packaging Details: standard exporting packing

Delivery Time: 10-15 days

Payment Terms: T/T, L/C, Western Union, MoneyGram

Supply Ability: 100sets/month

Gallery

API Standard TCI Tricone Rock Bit 200mm IADC545 Mining / Water Well Drill

Product Description

API Standard TCI 200mm IADC545 Tricone Rock Bit / Mining / Water Well / Drill Bit

Description

Tungsten Carbide Inserts Bits /TCI & Steel tooth tricone bits/MT, from 3 7/8 to 28 inch (3 7/8" ~ 28").
--- Our advantage & features:
1. Bearing polishing process improves the service life
2. Hardfacing and Tungsten Carbide Inserts for Leg and shirttail protection
3. Heel Inserts and Build up welding on the Steel milled teeth

TRICONE BITS, ENGINEERED TO DRILL:
IADC 117/217/327, IADC 417/437/517/537/637, Steel Milled Tooth and Chisel/ Scoop/ Conical/ Sphrical teeth
Suitable for Water, Oil, Gas, Geothermal well drilling, Mining and HDD drilling

NO.	IADC	Recommend Parameters		Suitable Formation
NO.	IADC	WOB (KN/mm)	RPM (r/min)	Suitable Formation
1	116,117	0.35~0.8	150~80	Extremly soft formation with low compressive strength and high drillability,such clay,mudstone,cretaceous
2	126,127	0.35~0.9	150~70	Soft formation with low compressive strength and high drillability,such as mudstone,gypsum,salinastone,soft shale,soft limestone
3	136,137	0.35~1.0	120~60	Soft to mid-soft formation with low compressive strength and high drillability,such mid-soft shale,anhydrite,mid-soft limestone,mid-soft sandstone and soft formation with hard interbeds
4	216,217	0.4~1.0	100~60	Soft to medium formation with low compressive strength,such as mid-soft shale,mid -soft limestone,mid-soft sandstone and soft formation with hard interbeds
5	246,247	0.4~1.0	80~50	Mid-hard formation with high compressive strength,such as hard shale,limestone,sandstone and dolomite
6	417,437,447	0.35~0.9	150~70	Extremely soft formation with low compressive strength and high drillability,such as clay,mudstone,cretaceous,gypsum,salinastone,soft shale and soft limestone
7	517,527	0.35~1.0	140~60	soft formation with low compressive strength ,such as mudstone,gypsum,salinastone,soft shale and soft limestone
8	537,547	0.45~1.0	120~50	Soft to medium formation with low compressive strength,such as mid-soft shale,mid -soft limestone,mid-soft sandstone and medium formation with harder abrasiveness interbeds
9	617,627	0.45~1.1	90~50	Mid-hard formation with high compressive strength,such as hard shale,limestone,sandstone,and dolomite
10	637	0.5~1.2	80~40	Hard formation with high compressive strength,such as sandstone,limestone,dolomite and anhydrite,marble

Note :The upper limits of WOB and RPM in above table should not be used simultaneously.

Technical Parameter

Basical Specification
Bit Size	200mm
IADC Code:	545 etc.
Thread Connection	2 3/8 API REG PIN
Series	rubber sealed / metal sealed

Packing of Tricone Rock Bit

Packing: standard exporting packing.
Delivery: Normally 7-10 days after your advanced payment.

The type we can supply:

API Standard TCI Tricone Rock Bit 200mm IADC545 Mining / Water Well Drill 0

Company Profile

API Standard TCI Tricone Rock Bit 200mm IADC545 Mining / Water Well Drill 1

Glorytek Industry (Beijing)Co.,Ltd.,

located in Beijing,China, is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for decades. We are supported and assisted by a highly experienced team of designers and engineers that enable us to complete all the assigned projects successfully as per the specified requirement from our clients.

Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering,underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.

Jane Cheng
Sales Representative

Glorytek Industry ( Beijing ) Co., Ltd.
Address:No.B-2507, DongWeiCheng, GuanZhuang,Chao Yang District, Beijing, China.
Tel: +86-10-52864265/52864786
Fax: +86-10-52037270
Mobile:+86-13426420230
