Home /Products/Tricone Rock Bit/Air Drilling Iadc 545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing

Air Drilling Iadc 545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing

1pc
MOQ
Negotiable
Price
Air Drilling Iadc 545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Air Drilling IADC545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing
Keyword: IADC545 Hard Rock Tricone Bit
IADC: IADC545 And Etc.
Application: Mining Drilling, HDD Trenchless, Well Drilling Etc.
Colors: Black, Blue, Etc.
Size: 7 7/8" (200mm)
Highlight:

air drilling hard rock tricone bit

,

iadc 545 hard rock tricone bit

,

tricone bit with elastomer sealed bearing
Basic Infomation
Place of Origin: China
Brand Name: GLORYTEK
Certification: SGS, TUV
Model Number: 200mm IADC545
Payment & Shipping Terms
Packaging Details: standard exporting packing
Delivery Time: 10-15 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 100sets/month
Product Description

Air Drilling IADC545 Hard Rock Tricone Bit for Oil well with Elastomer Sealed Bearing



Description
According to cutting material,tirocne bit can be divided into TCI bit and Steel Tooth Bit .
TCI is short for Tungsten Carbide Insert, tungsten carbide is regular hard material in rock drilling field, another material is diamond.
Inserts means Tungsten Carbide teeth that's fitting on cones of rotary drilling roller cone bits. API TCI tricone drill bit IADC617 have type of Rubber /Elastomer sealed bearing and Metal sealed bearing. We suggest that we had better choose metal face sealed bearing bits for deep rock wells with hard formations.For very deep well drilling, we recommend Metal-face sealed bearing tricone bits in drilling depth exceeds 1000 meters, For hard rock and long distance trenchless pilot hole drilling that length exceeds 300 meters we also recommend metal-face sealed bearing tricone bits.For water well drilling, shallow well drilling or shorter distance trenchless pilot hole drilling projects, elastomer(rubber) sealed bearing tricone bits has better cost performance.

Regular Sizes Regular IADC API Reg Pin Make-up Torque(N.m)
3 7/8"(98.4mm) 126/216/517/537/637 2 3/8 4100~4700
4 5/8"(117.4mm) 126/216/517/537/637 2 7/8 6100~7500
5 1/2"(139.7mm) 126/216/517/537/617/637 3 1/2 9500~12200
5 5/8"(142.8mm) 126/216/517/537/617/637 3 1/2 9500~12200
5 7/8"(149.2mm) 126/216/517/537/617/637 3 1/2 9500~12200
6"(152.4mm) 126/127/216/517/537/617/637 3 1/2 9500~12200
6 1/4"(158.7mm) 126/127/216/517/537/617/637 3 1/2 9500~12200
6 1/2"(165mm) 126/127/216/517/537/617/637 3 1/2 9500~12200
7 1/2"(190mm) 126/216/517/537/637 4 1/2 16300~21700
7 5/8"(193mm) 126/216/517/537/637 4 1/2 16300~21700
7 7/8"(200mm) 126/216/517/537/637 4 1/2 16300~21700
8 1/2"(215.9mm) 117/127/217/437/517/537/617/637 4 1/2 16300~21700
9 1/2"(241.3mm) 117/127/217/437/517/537/617/637 6 5/8 38000~43400
9 7/8"(250.8mm) 117/127/217/437/517/537/617/637 6 5/8 38000~43400
10 5/8(269.8mm) 117/127/137/217/517/537/617/637 6 5/8 38000~43400
11 5/8(295.3mm) 117/127/137/217/517/537/617/637 6 5/8 38000~43400
12 1/4"(311.1mm) 114/127/217/437/517/537/617/637 6 5/8 38000~43400
13 5/8"(346.0mm) 127/217/517/537/617/637/737/837 6 5/8 38000~43400
14 3/4"(374.6mm) 127/217/517/537/617/637/737/837 7 5/8 46100~54200
17 1/2"(444.5mm) 114/115/125/215/515/535/537/615/635 7 5/8 46100~54200
20''(508.0mm) 114/115/125/215/515/535/537/615 7 5/8 46100~54200
22''(558.8mm) 114/115/125/215/515/535/537/615 7 5/8 46100~54200
24''(609.6mm) 114/115/125/215/515/535/537/615 7 5/8 46100~54200
26"(660.4mm) 114/115/125/215/515/535/537/615 7 5/8

Technical Parameter

Basical Specification
Bit Size 200mm
IADC Code: 545 etc.
Thread Connection 2 3/8 API REG PIN
Series rubber sealed / metal sealed


Packing of Tricone Rock Bit


Packing: standard exporting packing.
Delivery: Normally 7-10 days after your advanced payment.



The type we can supply:

Air Drilling Iadc 545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing 0



Company Profile



Air Drilling Iadc 545 Hard Rock Tricone Bit For Oil Well With Elastomer Sealed Bearing 1

Glorytek Industry (Beijing)Co.,Ltd.,

located in Beijing,China, is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for decades. We are supported and assisted by a highly experienced team of designers and engineers that enable us to complete all the assigned projects successfully as per the specified requirement from our clients.

Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering,underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.




Jane Cheng
Sales Representative

Glorytek Industry ( Beijing ) Co., Ltd.
Address:No.B-2507, DongWeiCheng, GuanZhuang,Chao Yang District, Beijing, China.
Tel: +86-10-52864265/52864786
Fax: +86-10-52037270
Mobile:+86-13426420230
