Small Mobile Exploration Drilling Rig Light Weight 1404m Depth

1
MOQ
Negotiable
Price
Small Mobile Exploration Drilling Rig Light Weight 1404m Depth
Features Gallery Product Description Request A Quote
Features
Specifications
Name: GL1080 Small Mobile Man Portable Light Weight Exploration Drilling Rigs
Keyword: Light Weight Exploration Drilling Rigs
Depth: 1404m
Drill Dia.: BTW, NTW,HTW, PQ
Weight: 29*4kg
Working Presure: 28Mpa
Highlight:

Mobile Exploration Drilling Rig 1404m

,

Small Exploration Drilling Rig

,

1404m Exploration Drilling Rig

Basic Infomation
Place of Origin: China
Brand Name: GLORYTEK
Certification: CE
Model Number: GL1080
Payment & Shipping Terms
Packaging Details: Standard exporting packing
Delivery Time: 20 days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/P, D/A
Supply Ability: 30 sets/month
Product Description

GL1080 Small Mobile Man Portable Light Weight Exploration Drilling Rigs



Description:



The drilling rig can be disassembled and lifted up the mountain by manual transportation. It uses Rexroth hydraulic system and Japanese Kubota diesel engine. It has the advantages of light weight and high power. All parts are of the highest-end brand, and the material is the lightest material.
This machine can use BTW, NTW, HTW, PTW, or BQ, NQ, HQ, PQ. The TW series has thin-walled drill pipes, which are light in weight and suitable for mountainous terrain. The Q series is relatively heavy, and it is relatively durable when it encounters complex formations.
Weighted less: Integration of oil cylinder and guide rail; Aluminium alloy ground beam;
Faster: The doubling mast mechanism helps drilling faster and achieving better concentricity of coordinate cones, better stability and longer penetration.
More fuel-efficient: Thread compensation makes drill pipe more durable. Variable pump and motor are more in line with any drilling conditions. Only 1 liter of oil is needed for 1 meter 1s drilling, to which three self-developed patent technologies are applied such as oil cylinder guide rail device, doubling mechanism device and thread compensation device.





Tehnical Parameter:



Models
GL-1080
GL-780
GL-580
GL-380
Technical Parameters
Drilling Capacity
Rod
Core Diameter
Drilling Depth(M)
Drilling Depth(M)
Drilling Depth(M)
Drilling Depth(M
BTW
42mm
1404
1404
754
494
NTW
56mm
1080
780
580
380
HTW
71mm
540
390
290
152
PQ
84mm
216
117
87

Hydraulic System
The variable pump(rexroth)
mpa) Presure
28
28
28
28
Cooling
Water-cooling
Water-cooling
Water-cooling
Water-cooling
Weight(kg)
29*4
29*3
29*2
29
The hydraulic oil tank Weight(kg)

45
32
23
Work station Weight(kg)
150
120
105
90




Certificate



Small Mobile Exploration Drilling Rig Light Weight 1404m Depth 0




Customer Visting

Small Mobile Exploration Drilling Rig Light Weight 1404m Depth 1

Company Profile

Small Mobile Exploration Drilling Rig Light Weight 1404m Depth 2

Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
Glorytek Drill is one of the most important member of “Sundrill Corporation”.Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.





FAQ
Q: How can we choose a suitable water well drill rig?
A: We normally recommend a suitable model according to drilling depth, drilling hole dia. and layer condition on site.


Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.


Q: What is your payment terms?
A: We can accept T/T,L/C.


Q:.What is your MOQ? How long is the delivery time?
A: Our MOQ is 1 sets. Normally for drill rig, the delivery time is about 25-30 days after receiving payment, the drilling tools would be about 15 days.


Q:. How long is the warranty?
A: The guarantee period for mainframe is one year (excluding the quick wear parts).


Q: Can we print my Logo on the products?
A: Yes, we can. We support OEM .
