GL300AT multifunctional crawler well drill is a new,highly-effective ,energy-saving and multifunctional hydraulic drill and it is specialized in drilling well ,monitoring well, geothermal air-conditioning hole drilling operations.
The drill rig is equipped with hydraulic motor rotation with a high power,propulsion and lifting of cylinder and down-hole impacter with high blast pressure,to realize high effectiveness of drilling footage and lowenergy consumption.
Drill Rig Spec. | |||||||||
Max. drilling depth | 300m | ||||||||
borehole dia. | 105-320mm | ||||||||
recommended working pressure | 1.2-3.5Mpa | ||||||||
Recommended air consumption | 16-55m3/min | ||||||||
Drill rod length | 6m/3m | ||||||||
Drill rod dia. | 89mm/102mm/114mm | ||||||||
Feeding efficiency | 10-40m/h | ||||||||
Winch lifting force | 1.1T (optional) | ||||||||
DTH hammer | Medium and high pressure type | ||||||||
Truck Chassis Specification | |||||||||
Brand | Sinotruk HOWO 6x4 | ||||||||
Cab | T5G-W | ||||||||
Diesel Engine Model | MC09.35B-60(Displacement:9.0L, 6-cylinder) | ||||||||
Diesel Engine Power | 350HP | ||||||||
Drive Type | 6x4 | ||||||||
Wheelbase | 5700+1350 | ||||||||
Tire specifications | 12.00R20 | ||||||||
Front axle | HF7 self-adjusting arm front axle | ||||||||
rear axle | ST16 self-adjusting arm double rear axle,Speed ratio 4.8 | ||||||||
gearbox | HW16709XST | ||||||||
other configuration | frame:8+5/300, 300L Aluminum alloy oil tank | ||||||||
Air Compressor Specification | |||||||||
Brand | Glorytek | ||||||||
Air pressure | 22bar | ||||||||
Air output | 24m³/min | ||||||||
Diesel engine | Yuchai YC6L310-H300 | ||||||||
Diesel engine power | 228Kw | ||||||||
Dimensions | 3560*1830*2050mm | ||||||||
Weight | 3560kgs | ||||||||
Delivery valve | G1 1 /2, G2 |
Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
Glorytek Drill is one of the most important member of “Sundrill Corporation”.Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
Q: How can we choose a suitable water well drill rig?
A: We normally recommend a suitable model according to drilling depth, drilling hole dia. and layer condition on site.
Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.
Q: What is your payment terms?
A: We can accept T/T,L/C.
Q:.What is your MOQ? How long is the delivery time?
A: Our MOQ is 1 sets. Normally for drill rig, the delivery time is about 25-30 days after receiving payment, the drilling tools would be about 15 days.
Q:. How long is the warranty?
A: The guarantee period for mainframe is one year (excluding the quick wear parts).
Q: Can we print my Logo on the products?
A: Yes, we can. We support OEM .
