Down The Hole DTH Drilling Hammer DHD112 For Foundation Drilling

1pc
MOQ
Negotiable
Price
Down The Hole DTH Drilling Hammer DHD112 For Foundation Drilling
Features Gallery Product Description Request A Quote
Features
Specifications
Name: GL112A DTH Drilling Hammer DHD112 Down The Hole Hammer For Foundation Drilling
Keyword: GL112A DTH Drilling Hammer DHD112
Model: GL112A
Shank: DHD112
Thread: 6 5/8 Reg Pin
Weight: 550KG
Highlight:

Down The Hole DTH Drilling Hammer

,

Foundation DTH Drilling Hammer

,

DHD112 Drilling Hammer

Basic Infomation
Place of Origin: China
Brand Name: GLORYTEK
Model Number: GL112A
Payment & Shipping Terms
Packaging Details: standard exporting packing
Delivery Time: 5days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10000pieces/month
Product Description

GL112A DTH Drilling Hammer DHD112 Down The Hole Hammer For Foundation Drilling



Description



Our DTH hammer and bits are compatible with CIR, DHD, QL,SD,Mission, etc. series of Atlas and Sandvik etc. They are with high efficiency, low failure rate and long service life. Even for all kinds of high hardness, high abrasive rocks and other harsh conditions, our drilling tools can also realize efficient and economical drilling.



DTH Hammer drilling is suitable for drilling into hard rock layers, and the drilling is not easy to be deflected, and it is more advantageous to use in water-deficient areas.



It is used to drill into hard rock layers and pebble layers, and the drilling efficiency can be increased several times to ten times compared with conventional rotary drilling and mechanical impact drilling, and has been promoted as an advanced technology.

Its application fields are constantly expanding. In the past, it was mainly used for drilling blasting holes in mines.



At present, it has been used in hydropower, railways, highways, water wells, building foundation piles, and geological exploration.





Technical Parameter



Model
GL112A
Drilling Dia. (ф/mm)
305-350MM
Hammer Length(mm)
1698.5MM
Outside Dia. (ф/mm)
275
Weight(kg)
550

 Working Pressure(Mpa)

1.8
Air Consumption (M3/Min.)
70
Recommended rotation speed
15-40rpm
Connection 1
API 6 5/8reg
Connection 2
DHD112





Applications


DTH hammers are widely used for mine, quarry, road construction for the drilling and blasting work, water well drilling, slope protection, anchoring, etc.


Features


1. Smooth performance and long service life of DTH hammer due to high quality alloy steel materials and advanced processing technology adapted.
2. Low problem rate and easy to maintenance due to simple, reliable and easy assemble and disassemble inner structure of hammer.



Packing


Packing: wooden box.
Delivery: Normally 5-7 days after down payment.
Shipping method: by express, by air or by sea



Company Profile



Down The Hole DTH Drilling Hammer DHD112 For Foundation Drilling 0
Glorytek Industry (Beijing) Co., Ltd. is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for more than 20 years. We are supported and assisted by highly experienced R&D team and enginners that enable us to complete all the assigned projects successfully as per clients' requirements.
Our factory covers an area of 250,000 square meters, construction area is about 150,000 square meters, having machining machinery, CNC processing center, friction welding machine, testing equipments etc. over 200 sets and more than 600 employees.



FAQ


Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.

Q: What is your payment terms?
A: We can accept T/T,L/C.

Q:.What is your MOQ?
A: No requirement for testing and trial order.
