Product Description:
The core drill rig of full hydraulic and rotator adopted the technology of wire-line coring has been the dominant type rig for solid mineral deposits prospecting in developed counties in the world. It is also the developing direction of drilling technique and drilling equipment in China. Under these circumstances, Glorytek Drill has developed the GLDX-4 core drill rig successfully according to the situation of China. This type of drill rig could substitute imported products. It could be applied to exploration and prospecting of geology, metallurgy, coal, petroleum, natural gas, groundwater and other industries.
Technical Parameters:
| Diesel Engine |
Model |
Cummins 6BTA5.9-C180 (turbocharged and charge water cooled) |
| Displacement |
5.9L (1.56 US Gallons) |
| Power |
132Kw (180HP) |
| Rated RPM(Factory setting) |
2200rpm |
| Drilling Capacity |
BQ |
1000m(3280feet) |
| NQ |
700m(2296 feet) |
| HQ |
500m(1640 feet) |
| PQ |
300m(984 feet) |
|
Support and Services:
Exploration Drilling Rigs Technical Support and Service
Warranty of GLDX-4 Full Hydraulic Crawler Core Drill Rig:
(1)Within the period of the first year after delivery, the main parts of Core Drilling Rig are guaranteed to be supplied free of charge once the problem caused by the quality issue.
(2) Service at working site: If need, our technical engineer can be dispatched to the working site for technical service,
but the expense of ticket, accommodation, diet, service charge shall be on buyer's account.
(3)Timely after-sale assistance shall be provided all the time.
Packing and Shipping:
The packaging and shipping of exploration drilling rigs is as follows:
- Exploration drilling rigs will be carefully packaged, using shockproof and water-resistant materials, to protect them from any damage during transportation.
- The packed exploration drilling rigs will be shipped out using reliable and secure delivery services.
- The delivery time for exploration drilling rigs will depend on the location of the customer.
FAQ:
Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.
Q: What is your payment terms?
A: We can accept T/T,L/C.
Q:.What is your MOQ? How long is the delivery time?
A: Our MOQ is 1set . The delivery time would be about 15 days.
Q: Can we print my Logo on the products?
A: Yes, we can. We support OEM .
