D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine

1
MOQ
Negotiable
Price
D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine
Features Gallery Product Description Request A Quote
Features
Specifications
Name: D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine
Keyword: D460A High Pressure DTH Rock Drill Rig
Drilling Depth: 35m
Hole Dia.: 115-152mm
Hammer: 4" Or 5"
Power: 264KW
Max. Working Pressure: 2.1Mpa
F.A.D: 19m3/min
Drill Pipe Storage: 6+1
Total Weight: 22t
Highlight:

D460A rock drill rig

,

High Pressure DTH rock drill rig

,

264KW Diesel Engine rock drilling equipment

Basic Infomation
Place of Origin: China
Brand Name: Glorytek
Certification: CE SGS
Model Number: D460A
Payment & Shipping Terms
Packaging Details: standard exporting packing
Delivery Time: 20 days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/P, D/A
Supply Ability: 40sets/month
Product Description

D460A High Pressure DTH Rock Drill Rig for Mining with 264KW diesel engine



Description



IGlorytek Industry (Beijing) Co., Ltd. presents the High Pressure DTH Drill Rig for Mining. This reliable and efficient drill rig is designed for mining operations and mineral exploration. With its high-quality construction and advanced features, it is the perfect choice for rock drilling in the mining industry. Equipped with a cabin, this surface drill rig offers enhanced comfort and control for operators. Experience the power and precision of our integrated DTH drilling rig for your mining needs.



At Glorytek Industry (Beijing) Co., Ltd., we are proud to present our state-of-the-art High Pressure DTH Drill Rig for Mining. This powerful and efficient drilling equipment is designed to revolutionize your mining operations.

Key Features:


  • Energy Efficient: Our drill rig, equipped with a screw air compressor and hydraulic system driven by a single power pack, reduces energy consumption by an impressive 35%. This not only helps you save on operational costs but also contributes to a greener environment.

  • Cost-Effective Maintenance: With the integrated hydraulic system and core components imported from Europe, our drill rig ensures reliable and convenient operation. The practical design greatly reduces maintenance work, resulting in a 50% decrease in maintenance costs.

  • Powerful Tramming Mechanism: The dual-*** hydraulic tramming mechanism provides exceptional off-road capability. The high torque rotary motor effortlessly handles any jamming of drill tools, ensuring smooth and uninterrupted drilling operations.

  • Efficient Dust Collection: Our two-stage dry dust collecting system not only keeps the environment clean and safe but also improves production efficiency. Say goodbye to the hassle of towing around a portable air compressor and enjoy the convenience of remo***nagement.




  •
  •

Specifications:


  • Product Name: High Pressure DTH Drill Rig for Mining

  • Keywords: Drill Rig for Mining, High Pressure Drill Rig, Rock Drilling Equipment, Crawler Drill Rig, DTH Drilling Equipment, Air Compressor Drill Rig, Surface Drill Rig, High Quality Mining Drill Rig, Rotary Drilling Machinery, Drilling Equipments for Mining, Drill Machine for Mining, Mining DTH Drill Rig, Rock Drilling Rig for Mining Operations, High Pressure Crawler Drill Rig, Drilling Rig with Air Compressor for Mining, Mining DTH Rock Drilling Equipment, High Quality Surface Drill Rig for Mining, Drilling Machinery for Mining Applications, Drill Machine for Mineral Exploration, Mining Drill Rig with Air Compressor, High Pressure DTH Rock Drilling Rig, Mining Drill Equipment, Reliable DTH Drill Rig for Mining, Advanced Surface Drill Rig, Efficient Mining Drill Rig
  •

Tehnical Parameter

Main Specifications D460A
Diesel Enggine
Model QSL8.9
Manufacturer Cummins (DCEC)
Rated Power 264KW
Rotation Speed 1900rpm
Capacity of Fuel Tank 750L
Screw Compressor
Air end Manufacturer JIUE
Model GE825
F.A.D 19m3/min
Working pressure (max.) 21bar
Function Specifications
Hole Range 115-152mm
Hole Depth 35m
Drill Pipe dia. 102mm
Drill pipe handling system 6+1
Hammer 4" or 5"
Rotation Speed 0-105rpm
Rotation torque 4435N.M
Drill pipe length 5m
Boom & Feed
Boom type single straight boom
Length of feed beam 9000mm
Feed extension 1300mm
Feed force(max.) 34.5kN
Feed type cylinder/wire
Travel length 5600mm
Feed rate(max.) 0.88m/s
Lifting force( max.) 67.6kN
Chassis
Tramming Speed High: 3km/h
Low: 1.5km/h
Climbing Ability( Max.) 25°
Ground Clearance 420mm
Traction force 156.2kN
Track Oscillation ±10°
Weight & Dimensions
Width 2700mm
Length 11550mm
Height 3560mm
Weight(w/o option) 22000kg

Explore our high-quality surface drill rig equipped with an on-board air compressor. Perfect for mining and rock drilling, our DTH drill rig offers exceptional performance and reliability. Choose Glorytek for all your drilling equipment needs.



We can supply air compressor, dth hammer, dth bit and drill pipe to work with mining dth drill rigs, clients can choose according to their project.

D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine 0

D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine 1



Company Profile

D460A High Pressure DTH Rock Drill Rig For Mining With 264KW Diesel Engine 2


Glorytek Industry (Beijing) Co., Ltd. specializes in providing high-quality, reliable, and efficient drilling equipment for mining operations. Our High Pressure DTH Drill Rig is designed for rock drilling in mining applications. Equipped with a crawler and air compressor, this advanced surface drill rig is perfect for mineral exploration. Trust Glorytek for all your mining drill equipment needs.



Welcome to Glorytek Industry (Beijing) Co., Ltd.

For over 20 years, we have been dedicated to manufacturing and exporting top-quality drilling equipment and parts. Our highly experienced R&D team and engineers ensure that we successfully complete all projects according to our clients' requirements.

Our factory, spanning an impressive 250,000 square meters, with a construction area of about 150,000 square meters, is equipped with state-of-the-art machinery including machining machinery, CNC processing center, friction welding machine, and testing equipment. With over 200 sets of machinery and a team of more than 600 skilled employees, we are committed to delivering excellence.

Our products have reached more than 60 countries worldwide, including Australia, Russia, South Africa, Zimbabwe, Malaysia, Indonesia, South Korea, France, Sweden, USA, Canada, and Haiti.

Introducing the High Pressure DTH Drill Rig for Mining

Our High Pressure DTH Drill Rig for Mining is designed to meet the demanding needs of the mining industry. With its advanced features and reliable performance, it is the perfect solution for your mining operations.

Key Features:


  • High Pressure Drill Rig

  • Rock Drilling Equipment

  • Crawler Drill Rig

  • DTH Drilling Equipment

  • Air Compressor Drill Rig

  • Surface Drill Rig

  • Rotary Drilling Machinery

  • Drilling Equipments for Mining

  • Drill Machine for Mining

  • Mining DTH Drill Rig

  • Rock Drilling Rig for Mining Operations

  • High Pressure Crawler Drill Rig

  • Drilling Rig with Air Compressor for Mining

  • Mining DTH Rock Drilling Equipment

  • High Quality Surface Drill Rig for Mining

  • Drilling Machinery for Mining Applications

  • Drill Machine for Mineral Exploration

  • Mining Drill Rig with Air Compressor

  • High Pressure DTH Rock Drilling Rig

  • Mining Drill Equipment

  • Reliable DTH Drill Rig for Mining

  • Advanced Surface Drill Rig

  • Efficient Mining Drill Rig




  •
  •

With our High Pressure DTH Drill Rig for Mining, you can expect reliable performance, advanced technology, and efficient drilling. Whether you are involved in mineral exploration or mining operations, our drill rig is designed to meet your needs.

Choose Glorytek Industry (Beijing) Co., Ltd. for top-quality drilling equipment and parts. Contact us today to learn more about our products and how we can assist you in your mining endeavors.



Packing



1. Drilling machine is bare packing, load into 40HQ container.
2. Drilling tools will be packed in cases or wooden boxes.
3.The delivery time for machine normally be 25-30 days after receiving payment. The drilling tools normally 3-5days if in stock.
4. Shipping by sea, air or express are all available.
