DHD360 DTH Drilling Hammer High Pressure For Water Well Drilling

1pc
MOQ
Negotiable
Price
DHD360 DTH Drilling Hammer High Pressure For Water Well Drilling
Features Gallery Product Description Request A Quote
Features
Specifications
Name: DTH Drilling Hammer DHD360 Water Well Drilling Tool Without Foot Valve
Keyword: DTH Drilling Hammer DHD360
Model: GL360SK
Shank: DHD360
Thread: 3 1/2 Reg Pin
Weight: 120kg
Highlight:

DHD360 DTH Drilling Hammer

,

Water Well DTH Drilling Hammer

,

dhd 360 hammer

Basic Infomation
Place of Origin: China
Brand Name: GLORYTEK
Model Number: GL360SK
Payment & Shipping Terms
Packaging Details: standard exporting packing
Delivery Time: 5days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10000pieces/month
Product Description

DTH Drilling Hammer DHD360 Water Well Drilling Tool Without Foot Valve



Description


DTH hammers are used in various down the hole operations like bench Drilling.



Our DTH hammer and bits are compatible with CIR, DHD, QL,SD,Mission, etc. series of Atlas and Sandvik etc. They are with high efficiency, low failure rate and long service life. Even for all kinds of high hardness, high abrasive rocks and other harsh conditions, our drilling tools can also realize efficient and economical drilling.

Selection of high-quality raw materials and advanced processing technology, more stable performance, longer life. The domestic advanced heat treatment process is adopted to ensure the good mechanical properties of the hammer.



Technical Parameter




High Pressure DTH Hammers
Item
GL360SK
Drilling Dia. (ф/mm)
165-219
Hammer Length(m)
1372
Outside Dia.(ф/mm)
152
Weight(kg)
92
Working Pressure(Mpa)
0.8-2.1
Air Consumption (m3/min)
43734
Torque(N.M)
1150
Impact Frequency (Times/Min.)
950-1650
Connection 1
API 3-1/2
Connection 2
Ф99.5-8



Applications


DTH hammers are widely used for mine, quarry, road construction for the drilling and blasting work, water well drilling, slope protection, anchoring, etc.


Features


1. Smooth performance and long service life of DTH hammer due to high quality alloy steel materials and advanced processing technology adapted.
2. Low problem rate and easy to maintenance due to simple, reliable and easy assemble and disassemble inner structure of hammer.



Packing


Packing: wooden box.
Delivery: Normally 5-7 days after down payment.
Shipping method: by express, by air or by sea



Company Profile



DHD360 DTH Drilling Hammer High Pressure For Water Well Drilling 0
Glorytek Industry (Beijing) Co., Ltd. is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for more than 20 years. We are supported and assisted by highly experienced R&D team and enginners that enable us to complete all the assigned projects successfully as per clients' requirements.
Our factory covers an area of 250,000 square meters, construction area is about 150,000 square meters, having machining machinery, CNC processing center, friction welding machine, testing equipments etc. over 200 sets and more than 600 employees.



FAQ


Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.

Q: What is your payment terms?
A: We can accept T/T,L/C.

Q:.What is your MOQ?
A: No requirement for testing and trial order.
