Name: 3 Inch Down To Hole Hammer Dhd / Ql / Cop / Mission / Sd / Numa
Brand: Glorytek Industry (Beijing) Co., Ltd.
SKU: DHD, SD, Ql, Mission, Numa, Cop
Price: 3,425.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Name: High Efficiency High Pressure DTH Drilling Hammers For DHD/Ql/Cop/Mission/SD/NUMA With Drill Bits

Keyword: High Efficiency High Pressure DTH Drilling Hammers

Hammer Sizes: 3"-12"

Shank Types: DHD, SD, Ql, Mission Etc.

Projects: Borehole Rock Drilling

MOQ: 1set

Highlight:

3 inch down to hole hammer

ql down to hole hammer

cop dth down the hole hammer

Basic Infomation

Place of Origin: China

Brand Name: GLORYTEK

Certification: SGS, TUV

Model Number: DHD, SD, Ql, Mission, Numa, Cop

Payment & Shipping Terms

Packaging Details: standard exporting packing

Delivery Time: 10-15 days

Payment Terms: T/T, L/C, Western Union, MoneyGram

Supply Ability: 100sets/month

Gallery

3 Inch Down To Hole Hammer Dhd / Ql / Cop / Mission / Sd / Numa

Product Description

High Efficiency High Pressure DTH Drilling Hammers for DHD/Ql/Cop/Mission/SD/NUMA with Drill Bits

Glorytek can provide CIR,DHD, QL,SD,Mission, etc. series of DTH Hammer and bits, that can compatible with Atlas and Sandvik etc. They are with high efficiency, low failure rate and long service life. Even for all kinds of high hardness, high abrasive rocks and other harsh conditions, our drilling tools can also realize efficient and economical drilling.

The DTH drilling hammer adopts rock drilling theory to design the internal structure size of the hammer, so that the hammer can obtain ideal energy transmission, with large single impact energy, high impact frequency and lower air consumption;
Selection of high-quality raw materials and advanced processing technology, more stable performance, longer life.
The domestic advanced heat treatment process is adopted to ensure the good mechanical properties of the hammer.

Application:

1. The piston has a simple structure and is not easily damaged.

2. Ideal energy transfer, fast drilling speed, low air consumption and low fuel consumption.

3. The parts used are few, the structure is simple, and all parts are hardened, so it has a long working life, few failures and convenient maintenance.

4. The joint and the clamping sleeve are connected with the outer cylinder by threads, which is easy to disassemble.

Technical Specifications:

High Pressure DTH Hammers
Item	GL345A	GL355K	GL360K	GL380K
Drilling Dia. (ф/mm)	105-130	140-152	165-219	203-350
Hammer Length(mm)	1034	1098	1372	1504
Outside Dia.(ф/mm)	98	124	152	180
Weight(kg)	39	70	92	230
Working Pressure(Mpa)	0.8-2.1	0.8-2.1	0.8-2.1	0.8-2.1
Air Consumption (M3/Min.)	3.5-15	4.5-18	43734	9.6-24.8
Torque(N.M)	335	800	1150	1870
Impact Frequency (Times/Min.)	≥800	840-1500	950-1650	1100-1550
Connection 1	API 2-3/8	API 2-3/8	API 3-1/2	API 4 1-2
Connection 2	Ф64-8	Ф84-8	Ф99.5-8	ф128-10

Packing of DTH Drilling Hammer

Packing: standard exporting packing.

Delivery: Normally 10 days after your advanced payment.

Company Profile

3 Inch Down To Hole Hammer Dhd / Ql / Cop / Mission / Sd / Numa 0

Glorytek Industry (Beijing) Co., Ltd. is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for more than 20 years. We are supported and assisted by highly experienced R&D team and enginners that enable us to complete all the assigned projects successfully as per clients' requirements.

Our factory covers an area of 250,000 square meters, construction area is about 150,000 square meters, having machining machinery, CNC processing center, friction welding machine, testing equipments etc. over 200 sets and more than 600 employees.

Our products have been exported more than 60 countries, including Australia, Russia, Soutn Africa, Zimbabwe, Malaysia, Indonesia, South Korea, France, Sweden, USA, Canada, Haiti etc.

Pre-sale service:

1.Select the right most suitable products.
2. According to the rock types, choosing the face type, button tooth type.
3. According to the different purpose, choosing the different body type

After-sale Service:

Delivery Time: Based on order quantity, normally it takes 20 days for production.Only 2 or 3 days if we have stock on your request size.

Quality Control: We have our professional QC and all the products will be strict inspection and testing for every order before shipping out.
Technical Support will be available in any time. We could provide the professional suggestion for you.

Only support to help solve the problem.

Shipping spare parts immediately if requested,
