High Pressure and Efficiency DTH Hammer Down the Hole Water Well Drilling Button Bits Tools
1.Description:
-DTH Hammer is one kind of basic drill equipmentfor drilling engineering. Pneumatic DTH hammer also named as pneumatic impactor, pneumatic DTH, DTH Impacter.
-Most DTH hammers are designed for use with the industry's most common rock drill bits shank types such as DHD, QL, Cop, Mission, SD, and so on.
-Our hammer and bits are made of high quality alloy steel with advanced heat threatment to assure the good drilling performance and long service life. They are widely used by our customers all over the world.
-Selection of high-quality raw materials and advanced processing technology, more stable performance, longer life. The domestic advanced heat treatment process is adopted to ensure the good mechanical properties of the hammer.
2.Quality of warranty:
Our products are made of high quality steel and all spares parts are inspected strictly before shipping. We have quickly responses for your complaint and suggestion.
Mainly used in hydrology and water well drilling, geological drilling without core, geological disaster prevention engineering and mine drilling and other fields. Suitable for gravel and hard rock applications, configure the special structure of the drill can also be used in the soft soil
3.Specifications:
| Item |
GL360K |
| Drilling Dia. (ф/mm) |
165-219 |
| Hammer Length(mm) |
1372 |
| Outside Dia.(ф/mm) |
152 |
| Weight(kg) |
92 |
| Working Pressure(Mpa) |
0.8-2.1 |
| Air Consumption (M3/Min.) |
9-26 |
| Torque(N.M) |
1150 |
| Impact Frequency (Times/Min.) |
950-1650 |
| Connection 1 |
API 3-1/2 |
| Connection 2 |
Ф99.5-8 |
|
Packaging & Shipping
Company Profile
Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
FAQ
Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.
Q: What is your payment terms?
A: We can accept T/T,L/C.
Q:.What is your MOQ?
A: No requirement for testing and trial order.
