High quality Heigh Pressure hammer DHD330 dth Hammer with hammer drill bit For Mining Well Drilling
1.Description:
-The application of the drilling diameter (105-130mm) mining blasthole achieves a record-breaking hole speed, and the medium and high pressure DTH impactor can convert the high wind into an unprecedented high perforation speed. It can work under the wind pressure of 0.8-2.1Mpa.
-Our hammer and bits are made of high quality alloy steel with advanced heat threatment to assure the good drilling performance and long service life. They are widely used by our customers all over the world.The optimal performance of DTH Hammers includes:High productivity,Longer service life and Low energy consumption.
-DTH Air Hammer gives you more power down the hole, making your investment produce more in less time.
Our DTH hammer is used in many different applications which include but are not limited to heavy construction, mining, oil and gas, quarries, and water-well.
2.Applications:
DTH hammers are widely used for mine, quarry, road construction for the drilling and blasting work, water well drilling, slope protection, anchoring, etc.
3.Specifications:
| Type and Technical Specification of High Pressure DTH Hammers |
| Item |
GL330 |
GL335 |
GL340A |
GL345 |
| Drilling Dia. (ф/mm) |
82-85 |
90-93 |
105-130 |
105-130 |
| Hammer Length(mm) |
867 |
908 |
1052 |
1034 |
| Outside Dia. (ф/mm) |
71 |
81 |
92 |
98 |
| Weight(kg) |
19 |
21.8 |
38 |
39 |
| Working Pressure(Mpa) |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
| Air Consumption (M3/Min.) |
4-12 |
4.3-14.2 |
3.5-18 |
3.5-15 |
| Torque(N.M) |
150 |
205 |
304 |
335 |
| Impact Frequency (Times/Min.) |
≥800 |
950-1500 |
≥800 |
≥800 |
| Connection 1 |
48.8×4.2 |
API 2-3/8 |
API 2-3/8 |
API 2-3/8 |
| Connection 2 |
ф47-6 |
ф53-8 |
ф64-8 |
ф64-8 |
|
Related Product
Company Profile
Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
FAQ
Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.
Q: What is your payment terms?
A: We can accept T/T,L/C.
Q:.What is your MOQ?
A: No requirement for testing and trial order.
