Product Description:
One of the key features of our Drill Rig Machines is the drill pipe length. We offer drill pipes with lengths of 6,000, 5,000, and 7,000 mm, giving you the flexibility to choose the right length for your drilling needs. Our drill pipes are also available in two different ODs, 114 and 102 mm, so you can choose the right size for your drilling operation.
Our Drill Rig Machines also come with a large fuel tank capacity of 750 L, allowing you to work for longer periods without having to refuel. This ensures that you can maximize your productivity and minimize downtime.
The Surface Integrated Drill Rig is also capable of drilling holes in the range of 138-165 mm, making it perfect for a wide range of drilling applications.
Our Surface Integrated Drilling Rig is also designed to provide maximum torque, with a maximum torque of 5,600 N.m. This ensures that you can drill through even the toughest of surfaces without any difficulty.
Overall, our Surface Integrated Drilling Rig is the perfect choice for anyone looking for a reliable and efficient drilling solution. With its advanced features and cutting-edge technology, our Integrated Drill Rig is sure to exceed your expectations and provide you with the results you need.
Features:
- Product Name: Drill Rig Machines
- Maximum torque: 5,600 N.m
- Dimensions: 11,560x2,700x3,560 Mm
- Feed beam: High Strength Aluminum Alloy
- Capacity FAD: 21 M3 / Min
- Recommended DTH hammer size: 5"/6"
- Integrated Blasthole drilling rig
- Air Compressor on Board DTH Drill Rig
- Surface Integrated Drilling Rig
Technical Parameters:
| Product Attribute |
|
| Type |
Surface Drill Rig |
| Rotation speed |
0 - 80 Rpm |
| Drill pipe OD |
114/102 Mm |
| Maximum working pressure |
24 Bar |
| Slope climbing ability |
25 Degree |
| Recommended DTH hammer size |
5"/6" |
| Drill pipe length |
6,000/5,000/7,000 Mm |
| Maximum hole depth with Auto handling |
35 M |
| Capacity FAD |
21 M3 / Min |
| Dimensions |
11,560x2,700x3,560 Mm |
| Fuel tank capacity |
750 L |
| Type |
DTH drill rig |
| Type |
Air Compressor on Board DTH Drill Rig |
Applications:
Support and Services:
- Remote technical support
- On-site technical support
- Training and education on product operation and maintenance
- Repair and maintenance services
- Spare parts and accessories sales
We are committed to ensuring that your Drill Rig Machine operates at peak performance and productivity, and our team is dedicated to providing you with the highest level of support and service.
